BM1800 series biological microscope
is equipped with achromatic objectives and wide field
eyepieces. It has clear images, wide field of view,
convenient operation
etc. It can be used for medical research, and many other
areas. It is the ideal instrument for medical treatment,
demonstrations and scientific research.
Features
- Wide field eyepieces and achromatic objectives,
the field of view is wide and clear.
- Coaxial coarse/fine focus system, with tension
adjustable and limit stopper, minimum division of
fine focusing: 2µm.
- Phase contrast unit is available, including phase
contrast condenser, phase contrast objective and centering
telescope.
- Photography eyepiece, digital & video camera,
CCD adapter, and digital camera adapter are available.
- Shipping weight: 17 lbs / 7.7 kg
Shipping size: 11.5x10x18 inch / 290x255x470 mm
|
|
Standard Configurations
|
|
|
|
Components
& Specification
|
BM1800A |
BM1800B |
|
B
|
T
|
B
|
T
|
|
Eyepiece
|
Wide
Field
|
WF10X(ø18mm) |
O
|
O
|
O
|
O
|
| WF16X(ø11mm) |
X
|
X
|
X
|
X
|
|
Objectives
|
Achromatic
|
SP4X/0.10 |
O
|
O
|
.
|
.
|
| SP10X/0.25 |
O
|
O
|
.
|
.
|
| SP40X/0.65(Spring) |
O
|
O
|
.
|
.
|
| SP100X/1.25(Spring) |
O
|
O
|
.
|
.
|
|
Semi-plan
Achromatic
|
PL4X/0.10 |
.
|
.
|
O
|
O
|
| PL10X/0.25 |
.
|
.
|
O
|
O
|
| PL40X/0.65(Spring) |
.
|
.
|
O
|
O
|
| PL100X/1.25(Spring) |
.
|
.
|
O
|
O
|
|
Eyepieces
Tube
|
Binocular
|
Compensation(inclination
of 30° 360° rotatable) |
O
|
..
|
O
|
.
|
| Sliding (inclination
of 45° 360° rotatable) |
X
|
.
|
X
|
.
|
|
Trinocular
|
Compensation(inclination
of 30° 360° rotatable) |
.
|
O
|
.
|
O
|
|
Stage
|
Mechanical
|
Size: 150x135mm.
Move range: 50x75mm |
O
|
O
|
O
|
O
|
|
Focus
System
|
Coaxial
coarse/fine
|
Gear rotate,
with tension adjustable and limit stopper system |
O
|
O
|
O
|
O
|
|
Nosepiece
|
Quadruple |
O
|
O
|
O
|
O
|
| Quintuple |
X
|
X
|
X
|
X
|
|
Condenser
|
Abbe
condenser NA1.25, rack & pinion adjustment |
O
|
O
|
O
|
O
|
|
Light
Source
|
LED
illumination |
X
|
X
|
X
|
X
|
| Illumination:
6V 20W halogen lamp, adjustable brightness, 110V or 220V |
O
|
O
|
O
|
O
|
|
Collector
|
Compose
with field diaphragm |
X
|
X
|
X
|
X
|
|
CCD
Camera Adapter
|
0.4X,
1X |
X
|
X
|
X
|
X
|
Note: "O"is
standard accessores; "X" is optional accessories.
"B" is Binocular; "SP" is Semi-Plan Achromatic.
|
 |
|
